Look Ahead Example

1 collaborator

Uri Wilensky (Author)

WHAT IS IT?

This code example shows how to have turtles look ahead before they move. By looking ahead, a turtle can determine what is in front of it and take a particular action. Looking ahead is most appropriate in situations where the turtle is not supposed to go "on top of" certain agents. This can be extremely useful for something like barriers or walls, which the turtle shouldn't move through.

In this example, four turtles are placed in a world with a checkerboard-like pattern of blue barriers on which they are not allowed to step. Before the turtles step forward they always check ahead to see if they are about to move into a wall using the patch-ahead primitives. patch-ahead n reports the patch that the turtle would be on if it were to move forward n steps (e.g., by executing fd n). In this example, we want turtles to always move one step at a time, so we always use patch-ahead 1.

In addition to simulating barriers, this technique can also be used to test whether a turtle is near something important, such as food or another turtle.

Note that the code in this model only prevents the turtle from landing on a blue patch. It doesn't prevent the turtle from:

following a path which crosses a blue patch
visually touching a blue patch

The turtles may cross a blue patch because in NetLogo the fd 1 command is equivalent to jump 1 -- in other words, the turtle simply disappears from its old location and reappears in its new location, rather than moving continuously. You could add more code to the model to ensure that the turtle's path never crossed a blue patch, but the math for that gets a bit complicated.

The turtles may visually touch a blue patch because to NetLogo, the turtles are really just their center points. We represent the turtle visually with a certain size and shape, but to NetLogo, the turtle is a point with no extent, and that point is always on one and only one patch. Again, you could add "collision detection" code to the model to ensure that the center point never came within a certain distance of any patch, but the math for that would get complicated. This kind of "collision detection" is not built in to NetLogo.

RELATED MODELS

Next Patch Example
One Turtle Per Patch Example

To see this in use in real models see Ants, Slime, Gas Chromatography, Simple Kinetics, GasLab and Connected Chemistry models, various games, and Wealth Distribution.

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

;;  This procedure sets up the patches and turtles

to setup
  ;;  Clear everything.
  clear-all

  ;;  This will create a "checkerboard" of blue patches.  Every third patch will be
  ;;  blue (remember modulo gives you the remainder of a division).
  ask patches with [pxcor mod 3 = 0 and
                    pycor mod 3 = 0]
    [ set pcolor blue ]

  ;;  This will make the outermost patches blue.  This is to prevent the turtles
  ;;  from wrapping around the world.  Notice it uses the number of neighbor patches rather than
  ;;  a location. This is better because it will allow you to change the behavior of the turtles
  ;; by changing the shape of the world (and it is less mistake-prone)
  ask patches with [count neighbors != 8]
    [ set pcolor blue ]

  ;;  This will create turtles on 200 randomly chosen
  ;;  black patches.
  ask n-of 200 (patches with [pcolor = black])
  [
    sprout 1
      [ set color red ]
  ]
  reset-ticks
end

;;  This procedure makes the turtles move

to go
  ask turtles
  [
    ;;  This important conditional determines if they are about to walk into a blue
    ;;  patch.  It lets us make a decision about what to do BEFORE the turtle walks
    ;;  into a blue patch.  This is a good way to simulate a wall or barrier that turtles
    ;;  cannot move onto.  Notice that we don't use any information on the turtle's
    ;;  heading or position.  Remember, patch-ahead 1 is the patch the turtle would be on
    ;;  if it moved forward 1 in its current heading.
    ifelse [pcolor] of patch-ahead 1 = blue
      [ lt random-float 360 ]   ;; We see a blue patch in front of us. Turn a random amount.
      [ fd 1 ]                  ;; Otherwise, it is safe to move forward.
  ]
  tick
end


; Public Domain:
; To the extent possible under law, Uri Wilensky has waived all
; copyright and related or neighboring rights to this model.
