;;; AGENTS DEFINITIONS
;;;


globals [
  involve-chance  ;; The chance out of 100 that an corporate volunteer will pass on institutional during one hour of exposure.
  support-show    ;; How long a person will be involved according support gives.

  slider-check-1    ;; Temporary variables for slider values, so that if sliders
  slider-check-2    ;;   are changed on the fly, the model will notice and
  slider-check-3    ;;   change volunteers's tendencies appropriately.
]

turtles-own [
  involved?          ;; If true, the person is involved.  It may be influenced or not.
  influenced?        ;; If true, the involving is influenced (and involved? must also be true).
  involve-length     ;; How long the person has been involved.
  enrolled?          ;; If true, the person is working for social cause.
  enroll-length      ;; How long the person has enrolled in social cause.


  work-exposure      ;; How long the person will work in social causes.
  supporting-tendency;; How likely the person is to support social causes.
  social-networks-use;; The percent chance a person uses social networks.

  partner            ;; The person that is our current partner (maybe influencer) in a work exposure.
]

;;;
;;; SETUP PROCEDURES
;;;

to setup
  __clear-all-and-reset-ticks
  setup-globals
  setup-people
  setup-plot
  update-plot
end

to setup-globals
  reset-ticks
  set involve-chance 30    ;; if you have social network using tendency,
                           ;; you have a 10% chance of being involved
  set support-show 30.0    ;; support show up 1 hour after working
  set slider-check-1 average-work-exposure
  set slider-check-2 average-supporting-tendency
  set slider-check-3 average-social-networks-use
end

;; Create carrying-capacity number of volunteers half are righty and half are lefty
;;   and some are involved in social causes.  Also assigns colors to people with the ASSIGN-COLORS routine.

to setup-people
  crt volunteers
    [ setxy random-xcor random-ycor
      set influenced? false
      set enrolled? false
      set partner nobody
      ifelse random 2 = 0
        [ set shape "person righty" ]
        [ set shape "person lefty" ]
      ;; 10% of the people start out involved.
      set involved? (who < volunteers * 0.10)
      if involved?
        [ set involve-length random-float support-show ]
      assign-work-exposure
      assign-supporting-tendency
      assign-social-networks-use
      assign-color ]
end

;; Different volunteers are displayed in 3 different colors depending on activities
;; green is institutional
;; blue is corporate
;; gray is influencer related to partner

to assign-color  ;; turtle procedure
  ifelse not involved?
    [ set color green ]
    [ ifelse influenced?
      [ set color gray ]
      [ set color blue ] ]
end

;; RANDOM-NEAR distribution implementing.

to assign-work-exposure  ;; turtle procedure
  set  work-exposure random-near average-work-exposure
end

to assign-supporting-tendency  ;; turtle procedure
  set supporting-tendency random-near average-supporting-tendency
end

to assign-social-networks-use  ;; turtle procedure
  set social-networks-use random-near average-social-networks-use
end

to-report random-near [center]  ;; turtle procedure
  let result 0
  repeat 40
    [ set result (result + random-float center) ]
  report result / 20
end

;;;
;;; GO PROCEDURES
;;;

to go
  if all? turtles [influenced?]
    [ stop ]
  check-sliders
  ask turtles
    [ if involved?
        [ set involve-length involve-length + 1 ]
      if enrolled?
        [ set enroll-length enroll-length + 1 ] ]
  ask turtles
    [ if not enrolled?
        [ move ] ]
  ;; Righties are always the ones to initiate influencing.
  ask turtles
    [ if not enrolled? and shape = "person righty" and (random-float 10.0 < supporting-tendency)
        [ enroll ] ]
  ask turtles [ disenroll ]
  ask turtles [ involve ]
  ask turtles [ assign-color ]
  tick
  update-plot
end

;; Each tick a check is made to see if sliders have been changed.

to check-sliders
  if (slider-check-1 != average-work-exposure)
    [ ask turtles [ assign-work-exposure ]
      set slider-check-1 average-work-exposure ]
  if (slider-check-2 != average-supporting-tendency)
    [ ask turtles [ assign-supporting-tendency ]
      set slider-check-2 average-supporting-tendency ]
  if (slider-check-3 != average-social-networks-use)
    [ ask turtles [ assign-social-networks-use ]
      set slider-check-3 average-social-networks-use ]
end

;; People move about at random.

to move  ;; turtle procedure
  rt random-float 360
  fd 1
end

;; Volunteers have the chance to participate in social activities.

to enroll  ;; turtle procedure -- righties only!
  let potential-partner one-of (turtles-at -1 0)
                          with [not enrolled? and shape = "person lefty"]
  if potential-partner != nobody
    [ if random-float 10.0 < [supporting-tendency] of potential-partner
      [ set partner potential-partner
        set enrolled? true
        ask partner [ set enrolled? true ]
        ask partner [ set partner myself ]
        move-to patch-here ;; move to center of patch
        move-to patch-here ;; partner moves to center of patch
        set pcolor gray - 3
        ask (patch-at -1 0) [ set pcolor gray - 3 ] ] ]
end

;; If two diferents kind of volunteers work together in social cause it's probabbly one of them be influenced,
;; in order to work in social causes.

to disenroll  ;; turtle procedure
  if enrolled? and (shape = "person righty")
    [ if (enroll-length >  work-exposure) or
         ([enroll-length] of partner) > ([ work-exposure] of partner)
        [ set enrolled? false
          set enroll-length 0
          ask partner [ set enroll-length 0 ]
          set pcolor black
          ask (patch-at -1 0) [ set pcolor black ]
          ask partner [ set partner nobody ]
          ask partner [ set enrolled? false ]
          set partner nobody ] ]
end

;; Involving occurs if volunteer corporative is influenced.

to involve  ;; turtle procedure
  if enrolled? and involved? and not influenced?
    [ if random-float 11 > social-networks-use or
         random-float 11 > ([social-networks-use] of partner)
        [ if random-float 100 < involve-chance
            [ ask partner [ set involved? true ] ] ] ]
end
;;;
;;; PLOTTING PROCEDURES

to setup-plot
  set-current-plot "Populations"
  set-plot-y-range 0 (volunteers + 50)
end

to update-plot
  set-current-plot "Populations"
  set-current-plot-pen "Institutional"
  plot count turtles with [not involved?]
  set-current-plot-pen "Corporate"
  plot count turtles with [involved?] -
       count turtles with [influenced?]
end ;
;;; MONITOR PROCEDURES
;;

to-report %involved
  ifelse any? turtles
    [ report (count turtles with [involved?] / count turtles) * 100 ]
    [ report 0 ]
end


; Copyright 2012 Yannick Patrick Carrasco Merma - San Ignacio de Loyola University. All rights reserved.
; The full copyright notice is in the Information tab.
