Contagion/ Social Influence- Jiawei Fu- Version 2

Contagion/ Social Influence- Jiawei Fu- Version 2 preview image

1 collaborator

Default-person Jiawei Fu (Author)


(This model has yet to be categorized with any tags)
Visible to everyone | Changeable by everyone
Model was written in NetLogo 5.2.0 • Viewed 254 times • Downloaded 14 times • Run 0 times
Download the 'Contagion/ Social Influence- Jiawei Fu- Version 2' modelDownload this modelEmbed this model

Do you have questions or comments about this model? Ask them here! (You'll first need to log in.)

Info tab cannot be displayed because of an encoding error

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

;;; Setup Procedures ;;;

to setup
  set-default-shape turtles "circle"
  nw:set-context turtles links
  ;; make the initial network of two turtles and an edge
  make-node nobody        ;; first node, unattached
  make-node turtle 0      ;; second node, attached to first node

;;; Main Procedures ;;;

to go
  ;; new edge is green, old edges are gray
  while [N < number-of-links]
  ask links [ set color gray ]
  make-node find-partner         ;; find partner & use it as attachment
                                 ;; point for new node
  if layout? [ layout ]
  ask one-of turtles [set color green]
  if any? turtles with [color = red]
    ask turtles with [color = green]
      ask link-neighbors [if random 100 <= probability-linked-affected [set color green]
        ask other turtles [
        if random 100 < probability-other-affected [set color green]]

;; used for creating a new node

to make-node [old-node]
  crt 1
    set color red
    if old-node != nobody
      [ create-link-with old-node [ set color green ]
        ;; position the new node near its partner
        move-to old-node
        fd 8
        set N N + 1

to-report find-partner
  report [one-of both-ends] of one-of links

;;; Layout ;;;

;; resize-nodes, change back and forth from size based on degree to a size of 1

to resize-nodes
  ifelse all? turtles [size <= 1]
    ;; a node is a circle with diameter determined by
    ;; the SIZE variable; using SQRT makes the circle's
    ;; area proportional to its degree
    ask turtles [ set size sqrt count link-neighbors ]
    ask turtles [ set size 1 ]

to layout
  ;; the number 3 here is arbitrary; more repetitions slows down the
  ;; model, but too few gives poor layouts
  repeat 3 [
    ;; the more turtles we have to fit into the same amount of space,
    ;; the smaller the inputs to layout-spring we'll need to use
    let factor sqrt count turtles
    ;; numbers here are arbitrarily chosen for pleasing appearance
    layout-spring turtles links (1 / factor) (7 / factor) (1 / factor)
    display  ;; for smooth animation
  ;; don't bump the edges of the world
  let x-offset max [xcor] of turtles + min [xcor] of turtles
  let y-offset max [ycor] of turtles + min [ycor] of turtles
  ;; big jumps look funny, so only adjust a little each time
  set x-offset limit-magnitude x-offset 0.1
  set y-offset limit-magnitude y-offset 0.1
  ask turtles [ setxy (xcor - x-offset / 2) (ycor - y-offset / 2) ]

to-report limit-magnitude [number limit]
  if number > limit [ report limit ]
  if number < (- limit) [ report (- limit) ]
  report number

There is only one version of this model, created over 5 years ago by Jiawei Fu.

Attached files

File Type Description Last updated
Contagion/ Social Influence- Jiawei Fu- Version 2.png preview Preview for 'Contagion/ Social Influence- Jiawei Fu- Version 2' over 5 years ago, by Jiawei Fu Download

This model does not have any ancestors.

This model does not have any descendants.
