Demonic Particles

Demonic Particles preview image

This model is seeking new collaborators — would you please help?

2 collaborators

Captura33 Paula Palacios (Author)
Sebastian Narvaez (Team member)

Tags

gaslab, maxwell, entropy

Tagged by Paula Palacios almost 8 years ago

Visible to everyone | Changeable by everyone
Model was written in NetLogo 5.3.1 • Viewed 732 times • Downloaded 29 times • Run 0 times
Download the 'Demonic Particles' modelDownload this modelEmbed this model

Do you have questions or comments about this model? Ask them here! (You'll first need to log in.)


Info tab cannot be displayed because of an encoding error

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

globals [ color-range ]
turtles-own [ speed mass last-collision neighbor-speeds ]

to setup

  clear-all

  draw-walls

  create-turtles population [

    setxy random-xcor random-ycor
    avoid-walls

    set shape "circle"
    set size 0.5
    set mass 20

    ;; make sure the speed is never 0
    set speed random-float 1
    if speed = 0 [ set speed 0.1 ]

    ;; set the particle's color according to its speed. Red is fast, Sky-blue is
    ;; slow and white-ish is average
    ifelse (speed >= 0.5)
    [ set color scale-color red speed 1.5 0.5 ]
    [ set color scale-color sky speed -0.5 0.5 ]

    ;; keeps a record of the speeds of the other turtles in
    ;; its room
    set neighbor-speeds ( list speed )
  ]

  reset-ticks
end

to draw-walls

  ;; draw membrane
  ask patches with [ pxcor = 0 ] [
    set pcolor yellow
  ]

  ;; draw the surrounding walls
  ask patches with [
      pxcor = max-pxcor or
      pxcor = min-pxcor or
      pycor = max-pycor or
      pycor = min-pycor ] [ set pcolor brown ]
end

;; reposition turtles that are in a wall patch

to avoid-walls

  if pxcor = 0 [
      set xcor (xcor + one-of [1 -1])
    ]
    if pxcor = max-pxcor [
      set xcor xcor - 2
    ]
    if pxcor = min-pxcor [
      set xcor xcor + 2
    ]
    if pycor = max-pycor [
      set ycor ycor - 2
    ]
    if pycor = min-pycor [
      set ycor ycor + 2
    ]
end

to go

  ask turtles [
    check-wall-collision
    update-neighbor-speeds
    if collide? [ check-for-particlecollision ]

    let max-speed max [ speed ] of turtles

    ifelse (speed >= 0.5)
    [ set color scale-color red ( speed / max-speed ) 1.5 0.5 ]
    [ set color scale-color sky ( speed / max-speed ) -0.5 0.5 ]

    ; normalize the speed
    forward speed / max-speed
  ]
  tick
end

;; bounce when collides with any wall

to check-wall-collision

  ; check collision with middle wall
  if [ pxcor ] of patch-ahead 1 = 0 [
    ifelse [ pcolor ] of patch-ahead 1 = yellow
      [ decide-traspase-door ]
      [ set heading (- heading) ]
  ]

  ; check collision with borders
  if abs ( [ pxcor ] of patch-ahead 1 ) = max-pxcor [
    set heading (- heading)
  ]
  if abs [ pycor ] of patch-ahead 1 = max-pycor [
    set heading (180 - heading)
  ]
end

to decide-traspase-door

  ;; Calculate the difference between a particle speed and its log of other particles' speed
  let speed-dif abs ( mean neighbor-speeds - speed )

  ifelse speed-dif < traspasing-threshold
    [ set heading (- heading) ]
    [
      jump 2
      set neighbor-speeds ( list speed )
    ]
end

;; update the mean speed that each particle perceives according to
;; their encounters with other turtles

to update-neighbor-speeds

  set neighbor-speeds sentence neighbor-speeds [ speed ] of turtles-on neighbors

  if length neighbor-speeds > memory [
    set neighbor-speeds sublist neighbor-speeds memory length neighbor-speeds
  ]
end


;; From now on, collision is implemented. This code comes from the Connected Chemistry 1
;; (Bike Tire) model, which can be found in the models library. Copyright to Uri Wilensky,
;; licensed under the Creative Commons Attribution-NonCommercial-ShareAlike 3.0 License.

to check-for-particlecollision ;; particle procedure
  if count other turtles-here  >= 1
  [
    ;; the following conditions are imposed on collision candidates:
    ;;   1. they must have a lower who number than my own, because collision
    ;;      code is asymmetrical: it must always happen from the point of view
    ;;      of just one particle.
    ;;   2. they must not be the same particle that we last collided with on
    ;;      this patch, so that we have a chance to leave the patch after we've
    ;;      collided with someone.
    let candidate one-of other turtles-here with
      [who < [who] of myself and myself != last-collision]
    ;; we also only collide if one of us has non-zero speed. It's useless
    ;; (and incorrect, actually) for two turtles with zero speed to collide.
    if (candidate != nobody) and (speed > 0 or [speed] of candidate > 0)
    [
      collide-with candidate
      set last-collision candidate
      ask candidate [ set last-collision myself ]
    ]
  ]
end

;; implements a collision with another particle.
;;
;; THIS IS THE HEART OF THE PARTICLE SIMULATION, AND YOU ARE STRONGLY ADVISED
;; NOT TO CHANGE IT UNLESS YOU REALLY UNDERSTAND WHAT YOU'RE DOING!
;;
;; The two turtles colliding are self and other-particle, and while the
;; collision is performed from the point of view of self, both turtles are
;; modified to reflect its effects. This is somewhat complicated, so I'll
;; give a general outline here:
;;   1. Do initial setup, and determine the heading between particle centers
;;      (call it theta).
;;   2. Convert the representation of the velocity of each particle from
;;      speed/heading to a theta-based vector whose first component is the
;;      particle's speed along theta, and whose second component is the speed
;;      perpendicular to theta.
;;   3. Modify the velocity vectors to reflect the effects of the collision.
;;      This involves:
;;        a. computing the velocity of the center of mass of the whole system
;;           along direction theta
;;        b. updating the along-theta components of the two velocity vectors.
;;   4. Convert from the theta-based vector representation of velocity back to
;;      the usual speed/heading representation for each particle.
;;   5. Perform final cleanup and update derived quantities.

to collide-with [ other-particle ] ;; particle procedure
  let mass2 0
  let speed2 0
  let heading2 0
  let theta 0
  let v1t 0
  let v1l 0
  let v2t 0
  let v2l 0
  let vcm 0



  ;;; PHASE 1: initial setup

  ;; for convenience, grab some quantities from other-particle
  set mass2 [mass] of other-particle
  set speed2 [speed] of other-particle
  set heading2 [heading] of other-particle

  ;; since turtles are modeled as zero-size points, theta isn't meaningfully
  ;; defined. we can assign it randomly without affecting the model's outcome.
  set theta (random-float 360)


  ;;; PHASE 2: convert velocities to theta-based vector representation

  ;; now convert my velocity from speed/heading representation to components
  ;; along theta and perpendicular to theta
  set v1t (speed * cos (theta - heading))
  set v1l (speed * sin (theta - heading))

  ;; do the same for other-particle
  set v2t (speed2 * cos (theta - heading2))
  set v2l (speed2 * sin (theta - heading2))


  ;;; PHASE 3: manipulate vectors to implement collision

  ;; compute the velocity of the system's center of mass along theta
  set vcm (((mass * v1t) + (mass2 * v2t)) / (mass + mass2) )

  ;; now compute the new velocity for each particle along direction theta.
  ;; velocity perpendicular to theta is unaffected by a collision along theta,
  ;; so the next two lines actually implement the collision itself, in the
  ;; sense that the effects of the collision are exactly the following changes
  ;; in particle velocity.
  set v1t (2 * vcm - v1t)
  set v2t (2 * vcm - v2t)


  ;;; PHASE 4: convert back to normal speed/heading

  ;; now convert my velocity vector into my new speed and heading
  set speed sqrt ((v1t * v1t) + (v1l * v1l))
  ;; if the magnitude of the velocity vector is 0, atan is undefined. but
  ;; speed will be 0, so heading is irrelevant anyway. therefore, in that
  ;; case we'll just leave it unmodified.
  if v1l != 0 or v1t != 0
    [ set heading (theta - (atan v1l v1t)) ]

  ;; and do the same for other-particle
  ask other-particle [
    set speed sqrt ((v2t ^ 2) + (v2l ^ 2))
    if v2l != 0 or v2t != 0
      [ set heading (theta - (atan v2l v2t)) ]
  ]
end
