SCARS

;%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
;%%%%%%%%%%%%%%%%%%%%%%%%% Experimention for SCARS %%%%%%%%%%%%%%%%%%%%%%%%%%%%
;%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
;%%%%% SCARS == SPATIO-TEMPORAL COGNITIVE AGENT-BASED RECOMMENDER SYSTEM %%%%%%
__includes
[
  "communication.nls"     ;; Library for ACL exchanging messages
  "bdi.nls"               ;; Library for Beliefs-desire-intention architecture
  "UserAgent.nls"        ;; Cars BDI behavior
]

extensions [gis array table]
globals
[
autobleue_data            ;; GIS dataset about electric recharge points in Nice
streets_data              ;; GIS dataset about streets in Nice Ville
nice_buildings            ;; GIS dataset about touristic POI in Nice Ville
center-x                  ;; center of the map
center-y                  ;; center of the map
mean-wait-time
number
random-accident-place
counter
]
breed [cars car]
breed [workPlaces workPlace]
breed [vertices vertice]
cars-own
[
   speed         ;; speed (optional in this demo)
   myposition    ;; my actual position
   last-stop     ;; last item in my path
   destination   ;; a destination where to go
   mypath        ;; a list of vertices to go to a destination
   step-in-path  ;; steps in the path
   destination-entrance
   beliefs       ;; information about their environment
   desires       ;; state of affairs that an agent want to accomplish
   intentions    ;; plan that allow an agent to achive its goals
   goals         ;; list of possible desires that an agent want to achieve
   trust         ;; the confidence degree
   distrust      ;; the non-confidence degree
   incoming-queue;; exchanged messages with others agents
   wait-time     ;; time waiting in traffic congestion
   time-of-simulation
]
patches-own[road? distance-work distance-home centroid? id entrance]
vertices-own [
  myneighbors          ;;agentset of neighboring vertices
  entrance?            ;;if it is an entrance to a building
  test                 ;;used to delete in test
  ;;the follwoing variables are used and renewed in each path-selection
  dist                 ;;distance from original point to here
  doone                 ;;1 if has calculated the shortest path through this point, 0 otherwise
  lastnode             ;;last node to this point in shortest path
  ]


;%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%Setup%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

to setup
  ca
  reset-ticks
  load-data
  make-streets
 ;; setup-destinations
  add-agents
  set number 15
end

to load-data

  ask patches [set pcolor white]
  set streets_data gis:load-dataset "paca/gis.osm_roads_free_1.shp";;;route sur Nice Ville
  set autobleue_data gis:load-dataset "Nice_shapefile/autobleue/autobleue.SHP";; Cartographie de point de recharge des autobleue sur Nice et environs
  ; set nice_buildings gis:load-dataset "Nice_shapefile/POI/export_musees_galeries_RGF93L93_shapefile.shp"
  draw
end

to draw
  setup-world-envelope
   gis:set-drawing-color white  gis:draw streets_data 1
   gis:set-drawing-color blue     foreach gis:feature-list-of autobleue_data [ gis:draw ? 1]
    ;gis:set-drawing-color black  gis:draw nice_buildings 1



 ;gis:set-drawing-color 25  gis:draw gmu-walkway 1.0

 ;identify centroids and assign IDs to centroids
 foreach gis:feature-list-of autobleue_data[
      let  center-point gis:location-of gis:centroid-of ?
      if not empty? center-point [
        ask patch item 0 center-point item 1 center-point
         [
        set centroid? true
        set id gis:property-value ? "IDENT"
        ]

 ]]
end

to setup-world-envelope
  gis:set-world-envelope gis:envelope-of autobleue_data
  let world gis:world-envelope
  let x0 (item 0 world + item 1 world) / 2  + center-x; center
  let y0 (item 2 world + item 3 world) / 2  + center-y
  let W0 zoom * (item 1 world - item 0 world) / 2 ; half-widths
  let H0 zoom * (item 3 world - item 2 world) / 2
  set world (list (x0 - W0) (x0 + W0) (y0 - H0) (y0 + H0))
  gis:set-world-envelope world
end

to center
  while [not mouse-down?] [wait .01]
  set center-x center-x + (mouse-xcor * gis-patch-size)
  set center-y center-y + (mouse-ycor * gis-patch-size)
  draw
end

to-report gis-patch-size ;; note: assume width & height same
  let world gis:world-envelope
  report (item 1 world - item 0 world) / (max-pxcor - min-pxcor)
end

to zoom-in  set zoom max list .01 precision (zoom - .1) 2  draw end

to zoom-out set zoom min list 1.2 precision (zoom + .1) 2  draw end

to make-streets
foreach gis:feature-list-of streets_data[

  foreach gis:vertex-lists-of ? ; for the road feature, get the list of vertices
       [
        let previous-node-pt nobody

        foreach ?  ; for each vertex in road segment feature
         [
          let location gis:location-of ?

          if not empty? location
           [
            ;ifelse any? vertices with [(xcor = item 0 location and ycor = item 1 location) ] ; if there is not a road-vertex here already
             ;[]
             ;[
             create-vertices 1
               [set myneighbors n-of 0 turtles ;;empty
                set xcor item 0 location
                set ycor item 1 location
                ask patch xcor ycor [set road? true]
                set size 0.2
                set shape "circle"
                set color brown
                set hidden? true


              ;; create link to previous node
              ifelse previous-node-pt = nobody
                 [] ; first vertex in feature
                 [create-link-with previous-node-pt] ; create link to previous node
                  set previous-node-pt self]
               ;]
           ]]] ]
  ;;delete duplicate vertices (there may be more than one vertice on the same patch due to reducing size of the map). therefore, this map is simplified from the original map.

  delete-duplicates

  ;;delete some nodes not connected to the network
  ask vertices [set myneighbors link-neighbors]
  delete-not-connected
  ask vertices [set myneighbors link-neighbors]


  ;;find nearest node to become entrance
  ask patches with [centroid? = true][set entrance min-one-of vertices in-radius 5 [distance myself]
    ask entrance [set entrance? true]]
   ; if show_nodes? [ask vertices [set hidden? false]]
   ; if show_entrances? [ask entrance [set hidden? false set shape "star" set size 0.5]]]

  ask links [set thickness 0.1 set color orange]
end

to delete-duplicates
    ask vertices [
    if count vertices-here > 1[
      ask other vertices-here [

        ask myself [create-links-with other [link-neighbors] of myself]
        die]
      ]
    ]
end

to delete-not-connected
 ask vertices [set test 0]
 ask one-of vertices [set test 1]
 repeat 500 [
   ask vertices with [test = 1]
   [ask myneighbors [set test 1]]]
 ask vertices with [test = 0][die]
end

to add-agents
   create-cars cars_number[
    set shape "car"
    set destination nobody
    set last-stop nobody
    set myposition one-of vertices
    move-to myposition
    set intentions []
    set desires table:make
    table:put desires "go-to-dest" 0.6
    set beliefs table:make
    set trust precision(random-float 1) 1 ;;random value in [0 1] interval
    set wait-time 0
    set incoming-queue []

   ]
;   create-cars 1[
;     set shape "car"
;     set label "BOB" set label-color black
;     set myposition one-of vertices
;     move-to myposition
;     set destination nobody
;     set last-stop nobody
;     set beliefs table:make
;     set desires table:make
;     table:put desires "go-to-dest" 0.9
;     set intentions []
;     set trust precision(random-float 1) 1 ;;random value in [0 1] interval
;     set wait-time 0
;     set incoming-queue []
;
;     ]
end

;%%%%%%%%%%%%%%%%%%%%% To Go %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

to shortest-path-select[todest]

     ;;use the A-star algorithm to find the shortest path (shortest in terms of distance)

     set mypath [] set step-in-path 0

     ask vertices [set dist 9999 set doone 0 set lastnode nobody set color brown]

     ask myposition [set dist 0 ] ;;distance to original node is 0


    while [count vertices with [doone = 0] > 0][
      ask vertices with [dist < 9999 and doone = 0][
         ask myneighbors [
           let dist0 distance myself + [dist] of myself    ;;renew the shorstest distance to this point if it is smaller
           if dist > dist0 [set dist dist0 set doone 0 ;;done=0 if dist renewed, so that it will renew the dist of its neighbors
             set lastnode myself]  ;;record the last node to reach here in the shortest path
           ;set color red  ;;all roads searched will get red
           ]
         set doone 1  ;;set done 1 when it has renewed it neighbors
      ]]
     ;;put nodes in shortest path into a list
     let x todest

     while [x != myposition] [
       if show_path? = true  [ask x [set color black] ] ;;highlight the shortest path
       set mypath fput x mypath
       add-intention (word "move-to" word "" x) (word "true")
       set x [lastnode] of x ]
       set last-stop last mypath
end

to go-to-dest
      if destination = nobody or destination = 0 [
       set destination one-of patches with [centroid? = true]
       set destination-entrance [entrance] of destination
       shortest-path-select destination-entrance
      ]
end

to go
  ask cars [
             move-forward listen-to-messages
             set goals objectives beliefs desires
             get-recommendation(goals)
             execute-intentions
             random-event
            if (speed = 0) and  (not any? patches with [centroid? = true] in-radius 3) [ set wait-time wait-time + 1]
            if not any? patches with [centroid? = true] in-radius 3   [set time-of-simulation ticks ]

  ]
     ask cars  [if not empty? table:to-list beliefs [send-messages(one-of table:to-list beliefs)]
                listen-to-messages]
   tick
end

to random-event
               if (ticks > 15) [set number number - 1
                             if number >= 0 [
                             set random-accident-place one-of vertices
                             ask random-accident-place [set pcolor red  set entrance? false]

                             if  (any? patches with [pcolor = red] in-radius 10) [ ;print "An accident just occured nearby"
                                                                                   table:put beliefs (word "" random-accident-place ) 0.7
                                                                                   set trust 0.7
                                                                                   ]
                                             ]
                                ]
               ;min-one-of vertices in-radius 100 [distance myself]
end

to move-forward
 let turtles-ahead turtles in-cone 2 45
             ifelse any? turtles-ahead
             [ slow
               rt 7 + random-float 3 ]
             [speed-up]
end

to slow
  if (speed > 0)
  [set speed speed - 1]
end

to speed-up
  let turtles-ahead turtles-at 0 1
  if (not any? turtles-ahead) [ set speed speed + 1]
  ;if ([road?] of patch-ahead 1 = true) and (not any? turtles-ahead) [ set speed speed + 1]
end

to draw-plots
  set mean-wait-time mean [wait-time] of cars
  set-current-plot-pen "mean-wait-time"
  plot mean-wait-time
end

to close-street[identifier]
  ask vertice identifier [die]
end

to compute-new-path-to-dest[dest]
  set destination-entrance [entrance] of dest
  shortest-path-select destination-entrance
end

to-report meters-per-patch ;; maybe should be in gis: extension?
  let world gis:world-envelope ; [ minimum-x maximum-x minimum-y maximum-y ]
  let x-meters-per-patch (item 1 world - item 0 world) / (max-pxcor - min-pxcor)
  let y-meters-per-patch (item 3 world - item 2 world) / (max-pycor - min-pycor)
  report mean list x-meters-per-patch y-meters-per-patch
end

;%%%%%%%%%%%%%%%%%%%%%%%%% Cars BDI Behavior %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

to-report objectives[B D]
;; input: beliefs and desires
;; output : goals which are the most desired and possible set of desires
let gamma 0
let g possible-desires B D gamma
report g stop
;;while [gamma < 1][
ifelse empty? table:to-list g [report g]
[
  let alpha min(map [last ?] table:to-list B)
   if alpha <= gamma [
     set alpha 1
     set gamma alpha]
   ]
;;]
end
;;;;;Elect a list of possible and coherent desires as goals ragrding a list of beliefs

to-report possible-desires [B D x]

loop [
let delta max(map [last ?] table:to-list D)
let Des table:make
foreach  table:keys D [
  if table:get D ? = delta
  [ let i ?
    table:put Des ? (table:get D ?)
   ;; if empty? table:to-list B [report Des]
   foreach table:keys B
     [ ;;print word "Not-"i
     if ? = word "Not-" i and table:get B  ? > x [table:remove Des i
                                                  table:remove D i
                                                 ]


     ]
  ]
  ]  if not empty? table:to-list Des [report Des  stop]]
end

to get-recommendation [g]
   ifelse (member? "go-to-dest" map first table:to-list g)[go-to-dest]
                                                            [do-nothing]
end

to evaluate-proposal[msg]
;send add-receiver get-sender msg add-content msg create-message "Accept proposal"
   ifelse (([trust] of turtle read-from-string get-sender msg) >= 0.5);; and (item 3 get-content msg > 0.5)
    [send add-receiver get-sender msg add-content msg create-message "Accept proposal"]
    [send add-receiver get-sender msg  create-message "Reject proposal"]
end
  ;;sending a proposal for similar agents

to send-messages [msg]
   broadcast-to other cars add-content msg create-message "proposal"
end

 ;;;to keep Listening to messages when running

to listen-to-messages
   let msg 0
   let performative 0
   while [not empty? incoming-queue ][
     set msg get-message
     set performative get-performative msg
     if performative = "proposal" [evaluate-proposal(msg)]
     if performative = "Accept proposal" [
                                          ;; update-intentions(msg)
                                          update-beliefs(msg)
                                          ;; update-desires(msg)
                                         ]
     if performative = "Reject proposal" [do-nothing]

     ]
end

to update-beliefs [msg]

  let proposal item 3 get-content msg
  let trustee  item 0 get-receivers msg
  ;;;;;;;;;;;;;;;;;;;;;;;;;Re-compute the recommandation if the proposal is accepted;;;;;;;;
  ask cars [
          ifelse table:has-key? beliefs item 0 proposal[do-nothing]  [
          table:put beliefs item 0 proposal min list (item 1 proposal) ([trust] of turtle read-from-string trustee)
          foreach intentions [if item 0 ? = word "move-to" word "" item 0 proposal [
           set speed 0
           set intentions []
           compute-new-path-to-dest destination
           execute-intentions] ;[let confiance [trust] of car read-from-string trustee set confiance 0 ]
          ]
          ]



  ]
;;;with Trust
end
