Insurgents & Soldiers Fighting

;;Insurgents & Soldiers Fighting
;; David Knoke, University of Minnesota
;; August 9, 2024

globals[
     jungle
     Ninsurgentsalive    ;; number of insurgents alive
     Ninsurgentsdead     ;; number of insurgents dead
     Pinsurgentsalive    ;; percentage of insurgents alive
     Pinsurgentsdead     ;; percentage of insurgents dead
     Nsoldiersalive      ;; number of soldiers alive
     Nsoldiersdead       ;; number of soldiers dead
     Psoldiersalive      ;; percentage of soldiers alive
     Psoldiersdead       ;; percentage of soldiers dead
     InsurgentsWin       ;; Insurgents eliminated all soldiers
     SoldiersWin         ;; Soldiers eliminated all insurgents
]

breed [ insurgents insurgent ]
breed [ soldiers soldier ]

insurgents-own [ detect detect_time ]
soldiers-own [ flockmates alert ]
patches-own [ density ]

to setup
  clear-all
  setup_patches
  setup_agents
  reset-ticks
end

to setup_patches
   ask patches
  [ set density (random 10000) ]
  repeat 2 [  diffuse density 1 ]
  ask patches
  [ set pcolor scale-color green density 9000 1000 ]
  set jungle max-n-of 20 patches [ density ]     ;; Create some high-density jungle patches
end

to setup_agents
   create-insurgents N-Insurgents
  [ set size 4
    setxy random-xcor random-ycor
    set color red
    set shape "person"
    set detect False
    set detect_time 0
    set InsurgentsWin 0
  ]

  create-soldiers N-Soldiers
  [ set size 4
    set xcor random-normal 0 1
    set ycor random-normal 0 1
    set color blue
    set shape "person"
    set flockmates no-turtles
    set alert False
    set SoldiersWin 0
  ]
end

to go
  if not any? insurgents [ stop ]
  if not any? soldiers [ stop ]
  ask insurgents [ insurgents_movement ]
  ask soldiers [ soldiers_movement ]
  tally
  tick
end

to insurgents_movement
  let p max-one-of patches in-radius 20 [ density ]
  if [ density ] of p > density [           ;;  Go to nearest high-density jungle patches to hide from soldiers
    face p
    forward  1 ]
  if any? soldiers in-radius 3              ;; If seen by soliders, stay detected for 20 ticks
  [ set detect_time 20 ]
  ifelse detect_time > 0
  [ set detect True
    face min-one-of turtles with [ color != red ] [ distance myself ]
    set heading heading + 180 + random-normal 0 30
    forward 1
  set detect_time detect_time - 1 ]
  [ set detect False ]
  if any? soldiers with [ alert = False ] in-radius 8   ;; Insurgents  attack nonalert soliders
  [
   insurgents-attack-soldiers
  ]
end

to soldiers_movement
  if any? insurgents in-radius 3
  or any? soldiers with [ alert = True ] in-radius 1
  [ set alert True ]
  ifelse any? insurgents with [ detect = True ]  in-radius 15
  [
   ifelse alert = True
  [ face min-one-of insurgents with [ detect = True ] [ distance myself ]
    set heading heading
    forward 1 ]
  [ flock
    forward 1 ]
  if any? insurgents-here
  [ soldiers-attack-insurgents ]
  ]
   [ set alert False
    flock
    forward 1 ]
end

to soldiers-attack-insurgents
  let x random 100
  ifelse x > Soldier_kill_rate           ;; Default kill rate is 50% of insurgents, 50% of soldiers
  [
  ask min-one-of insurgents with [ detect = True ] [ distance myself ] [ die ]
  ]
  [ die ]
end

to insurgents-attack-soldiers
  set detect True
  let x random 100
  ifelse x > Insurgent_kill_rate                          ; 70% kill soldier and 30% insurgent dies
  [ die ]
  [ let insurgent-target one-of soldiers with [ alert = False ] in-radius 8
    ask insurgent-target [ die ]
  ask soldiers in-radius 8 [ set alert True ]]
end


;;  Count the numbers and percentages of alive and dead insurgents and soldiers

to tally
  set Ninsurgentsalive count turtles  with [ color = red ]
  set Ninsurgentsdead (N-Insurgents - Ninsurgentsalive)
  set Nsoldiersalive count turtles  with [ color = blue ]
  set Nsoldiersdead (N-Soldiers - Nsoldiersalive)
  set Psoldiersalive (Nsoldiersalive / N-Soldiers) * 100
  set Psoldiersdead (Nsoldiersdead / N-Soldiers) * 100
  set Pinsurgentsalive (Ninsurgentsalive / N-Insurgents) * 100
  set Pinsurgentsdead (Ninsurgentsdead / N-Insurgents) * 100
;; Change one of two monitors to indicate which side eliminated the other
  if not any? turtles with [ color = red ] [ set SoldiersWin 1 ]
  if not any? turtles with [ color = blue ] [ set InsurgentsWin 1 ]
end




;; flocking code

to flock
  find-flockmates
  let nearest-neighbor min-one-of flockmates [distance myself]
  if any? flockmates
    [
      ifelse distance nearest-neighbor < 1
        [ separate ]
        [ align
          cohere ] ]
end

to find-flockmates
  set flockmates other soldiers in-radius 8
end

to find-nearest-neighbor
  let nearest-neighbor min-one-of flockmates [distance myself]
end

;;; SEPARATE

to separate
  let nearest-neighbor min-one-of flockmates [distance myself]
  turn-away ([heading] of nearest-neighbor) 1.5
end

;;; ALIGN

to align  ;; turtle procedure
  turn-towards average-flockmate-heading 5
end

to-report average-flockmate-heading
  let x-component sum [dx] of flockmates
  let y-component sum [dy] of flockmates
  ifelse x-component = 0 and y-component = 0
    [ report heading ]
    [ report atan x-component y-component ]
end

to cohere
  turn-towards average-heading-towards-flockmates 3
end

to-report average-heading-towards-flockmates
  let x-component mean [sin (towards myself + 180)] of flockmates
  let y-component mean [cos (towards myself + 180)] of flockmates
  ifelse x-component = 0 and y-component = 0
    [ report heading ]
    [ report atan x-component y-component ]
end

to turn-towards [new-heading max-turn]
  turn-at-most (subtract-headings new-heading heading) max-turn
end

to turn-away [new-heading max-turn]
  turn-at-most (subtract-headings heading new-heading) max-turn
end

to turn-at-most [turn max-turn]
  ifelse abs turn > max-turn
    [ ifelse turn > 0
        [ rt max-turn ]
        [ lt max-turn ] ]
    [ rt turn ]
end
