Recruiting Movement Supporters

;;  Recruiting Movement Supporters
;;  David Knoke and Tiffany Wu, University of Minnesota
;;  Last changed on August 3, 2024

extensions [nw ]         ;; Use NetLogo network extensions
breed [peoples people]   ;; Agents are called people

peoples-own              ;;  Attributes of people
[
  received?              ;; if true, the person accepted an invitation to attend a social movement event
]


globals [   ;; Globals enable counting the numbers of peoples with each of three colors
  initial-blue
  initial-red
  initial-green
  recruitpct
  resistpct
  neutralpct
]

to setup
  clear-all
  ask patches [set pcolor white]
  setup-peoples
  ask peoples [set size 4]
  ask peoples [set color blue]
  setup-spatially-clustered-network
  ask n-of N-Initiators peoples
    [ receive-invitation ]
  ask links [ set color black ]     ;; Make link color black
  setup-resist
  reset-ticks
end

to setup-peoples
  set-default-shape peoples "person"    ;;  Sets people shape to person
  create-peoples N-of-people            ;;  Create number of people
  [
    setxy (random-xcor * 0.90) (random-ycor * 0.90)    ;; Don't put people close to the edges
  ]
end

to setup-spatially-clustered-network
  let num-links (Average-people-degree * N-of-people) / 2

  ;; Generate links as before
  while [count links < num-links]
  [
    ask one-of peoples
    [
      let choice (min-one-of (other peoples with [not link-neighbor? myself]) [distance myself])
      if choice != nobody [ create-link-with choice ]
    ]
  ]

  ;; Ensure the network is a single connected component
  let components nw:weak-component-clusters
  while [length components > 1]  ;; While there's more than one component
  [
    let component1 item 0 components
    let component2 item 1 components

    ;; Connect a random agent from the first component to a random agent from the second
    ask one-of component1 [ create-link-with one-of component2 ]

    ;; Update the list of components
    set components nw:weak-component-clusters
  ]

  repeat 10
  [
    layout-spring peoples links 0.3 (world-width / (sqrt N-of-people)) 1
  ]
end

;; Use Resistance-threshold slider to set the probability for an experiment (0 to 100)
;; Assign a resistance probability (0 to 100) to every person; persons above the threshold value are resisters who turn red

to setup-resist
  ask peoples with [color = blue] [
    if random 100 <= Resistance-threshold [set color red]
  ]
end

to go
  if not any? peoples with [color = blue and any? link-neighbors with [color = green]]
    [ stop ]
  spread-invitation
  tally
  tick
end

to receive-invitation
  set received? true
  set color green
end

to spread-invitation
  ask peoples with [color = green]
    [ ask link-neighbors with [color = blue]    ;;   CHANGE ONLY BLUE TO GREEN    color 1 = green
            [ receive-invitation ] ]
end

;; Report mean network measures

to-report mean-closeness-centrality
  report mean [ nw:closeness-centrality ] of peoples
end

to-report mean-shortest-path-length
  report mean [ nw:mean-path-length ] of peoples
end

to-report mean-clustering-coefficient
  report mean [ nw:clustering-coefficient ] of peoples
end

to-report mean-betweenness
  report mean [ nw:betweenness-centrality ] of peoples
end

to tally
  set recruitpct count (peoples with [color = green]) / (count peoples) * 100
  set resistpct count (peoples with [color = red]) / (count peoples) * 100
  set neutralpct count (peoples with [color = blue]) / (count peoples) * 100
end
