globals [ patch-data ]

;; This procedure loads in patch data from a file.  The format of the file is: pxcor
;; pycor pcolor.  You can view the file by opening the file File IO Patch Data.txt
;; using a simple text editor.  Note that it automatically loads the file "File IO
;; Patch Data.txt". To have the user choose their own file, see load-own-patch-data.

to load-patch-data

  ;; We check to make sure the file exists first
  ifelse ( file-exists? "File IO Patch Data.txt" )
  [
    ;; We are saving the data into a list, so it only needs to be loaded once.
    set patch-data []

    ;; This opens the file, so we can use it.
    file-open "File IO Patch Data.txt"

    ;; Read in all the data in the file
    while [ not file-at-end? ]
    [
      ;; file-read gives you variables.  In this case numbers.
      ;; We store them in a double list (ex [[1 1 9.9999] [1 2 9.9999] ...
      ;; Each iteration we append the next three-tuple to the current list
      set patch-data sentence patch-data (list (list file-read file-read file-read))
    ]

    user-message "File loading complete!"

    ;; Done reading in patch information.  Close the file.
    file-close
  ]
  [ user-message "There is no File IO Patch Data.txt file in current directory!" ]
end

;; This procedure does the same thing as the above one, except it lets the user choose
;; the file to load from.  Note that we need to check that it isn't false.  This because
;; it will return false if the user cancels the file dialog.  There is currently only
;; one file to load from, but you can create your own using the function save-patch-data
;; near the bottom which saves all the current patches into a file.

to load-own-patch-data
  let file user-new-file

  if ( file != false )
  [
    set patch-data []
    file-open file

    while [ not file-at-end? ]
      [ set patch-data sentence patch-data (list (list file-read file-read file-read)) ]

    user-message "File loading complete!"
    file-close
  ]
end

;; This procedure will use the loaded in patch data to color the patches.
;; The list is a list of three-tuples where the first item is the pxcor, the
;; second is the pycor, and the third is pcolor. Ex. [ [ 0 0 5 ] [ 1 34 26 ] ... ]

to show-patch-data
  cp ct
  ifelse ( is-list? patch-data )
    [ foreach patch-data [ ask patch first ? item 1 ? [ set pcolor last ? ] ] ]
    [ user-message "You need to load in patch data first!" ]
end

;; This is the procedure that was used to create the file "File IO Patch Data.txt".
;; You can also use it to create your own files.  See File Output code example for more
;; details on File Output.

to save-patch-data
  let file user-new-file

  if ( file != false )
  [
    file-write file
    ask patches
    [
      file-write pxcor
      file-write pycor
      file-write pcolor
    ]
    file-close
  ]
end


; Public Domain:
; To the extent possible under law, Uri Wilensky has waived all
; copyright and related or neighboring rights to this model.
