CollaborativeRobotHubNet

1 collaborator

Corey Brady (Author)

WHAT IS IT?

(a general understanding of what the model is trying to show or explain)

HOW IT WORKS

(what rules the agents use to create the overall behavior of the model)

HOW TO USE IT

(how to use the model, including a description of each of the items in the Interface tab)

THINGS TO NOTICE

(suggested things for the user to notice while running the model)

THINGS TO TRY

(suggested things for the user to try to do (move sliders, switches, etc.) with the model)

EXTENDING THE MODEL

(suggested things to add or change in the Code tab to make the model more complicated, detailed, accurate, etc.)

NETLOGO FEATURES

(interesting or unusual features of NetLogo that the model uses, particularly in the Code tab; or where workarounds were needed for missing features)

RELATED MODELS

(models in the NetLogo Models Library and elsewhere which are of related interest)

CREDITS AND REFERENCES

(a reference to the model's URL on the web if it has one, as well as any other necessary credits, citations, and links)

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

extensions [ gpio ]

to do-hubnet-reset
  hubnet-reset
  set reset-hubnet false
end

to setup
  ca
  if (reset-hubnet) [ do-hubnet-reset ]
  gpio:set-mode "gpio7" "WRITE"
  let i 2
  while [ i <= 12 ]
  [
  gpio:set-mode (word "gpio" i) "WRITE"
  set i i + 2
  ]
  ask patches with [ pxcor < 0 ] [ set pcolor red - 3 ]
  ask patches with [ pxcor > 0 ] [ set pcolor green - 3 ]
  reset-ticks
end

to execute-votes [vote-left vote-right]
  let vlist get-votelist vote-left vote-right
  ;show vlist

  let i 2
  while [ i <= 12 ]
  [
    let towrite "LOW"
    if  item (-1 + i / 2) vlist = 1 [ set towrite "HIGH" ]

    gpio:digital-write (word "gpio" i) towrite
    ;show (word "gpio:digital-write " (word "gpio" i) towrite)
    set i i + 2
  ]
end

to-report get-votelist [ vleft vright ]
  let returnlist n-values 6 [0]
  if vleft > 0 [ set returnlist replace-item 0 returnlist 1 ]
  if vright > 0 [set returnlist replace-item 3 returnlist 1 ]
  let t floor ((abs vleft) / 2)
  let r (abs vleft) mod 2
  set returnlist replace-item 1 returnlist r
  set returnlist replace-item 2 returnlist t

  let tr floor ((abs vright) / 2)
  let rr (abs vright) mod 2
  set returnlist replace-item 4 returnlist rr
  set returnlist replace-item 5 returnlist tr

  report returnlist
end

to display-votes [vleft vright]
  ask patch -5 7 [ set plabel "left" ]
  ask patch (max-pxcor - 2) 7 [ set plabel "right" ]
  ask patch -5 -3 [ set plabel vleft ]
  ask patch (max-pxcor - 2) -3 [ set plabel vright ]
end

to kill
  gpio:digital-write "gpio7" "LOW"
end

to unkill
  gpio:digital-write "gpio7" "HIGH"
end

to hubnet-control
  if (reset-hubnet) [ do-hubnet-reset ]
  let lvotes 0
  let rvotes 0
  while [ hubnet-message-waiting? ]
  [
    hubnet-fetch-message
    ifelse (hubnet-enter-message? or hubnet-exit-message?)
    [ show "enter or exit" ]
    [
      if hubnet-message-tag = "left-forward" [ set lvotes lvotes + 1 ]
      if hubnet-message-tag = "left-backward" [ set lvotes lvotes - 1 ]
      if hubnet-message-tag = "right-forward" [ set rvotes rvotes + 1 ]
      if hubnet-message-tag = "right-backward" [ set rvotes rvotes - 1 ]
    ]
  ]
  set lvotes round (lvotes / sensitivity)
  set rvotes round (rvotes / sensitivity)
  if lvotes > 3 [ set lvotes 3 ]
  if rvotes > 3 [ set rvotes 3 ]
  if lvotes < -3 [ set lvotes -3 ]
  if rvotes < -3 [ set rvotes -3 ]

  display-votes lvotes rvotes
  execute-votes lvotes rvotes
end

There are 2 versions of this model.

		Uploaded by	When	Description	Download
		Corey Brady	over 10 years ago	fix switch state	Download this version
		Corey Brady	over 10 years ago	Initial upload	Download this version

Attached files

File	Type	Description	Last updated
CollaborativeRobotHubNet.png	preview	Preview for 'CollaborativeRobotHubNet'	over 10 years ago, by Corey Brady	Download
