Real Time Motion v01

globals
[
xlist
ylist
mxlist
mylist
x1_list
x2_list
y1_list
y2_list
vx_list
vy_list

smoothx
smoothy
smooth_x1
smooth_x2
smooth_y1
smooth_y2
smooth_vx
smooth_vy


times
mytime
]

to setup
  ca
  ask patches [set pcolor white]
  set mytime 0
  set xlist []
  set ylist []
end

to turtle-draw
  reset-ticks
  ifelse mouse-down?
    [ ;; first make sure there's a turtle (if the user just pressed
      ;; the mouse button, there won't be yet)
      if not any? turtles
        [ ask patch mouse-xcor mouse-ycor
            [ sprout 1
                [ pen-down
                  set shape "circle"
                  ;;; set pen-size 2 ht ] ] ]
                  set pen-size 4  ] ] ]
      ;; now that we're sure we have a turtle, we ask it to move
      ;; towards the mouse

      ask turtles [

        set mxlist [] set mylist [] set times []  set x1_list [] set x2_list [] set y1_list [] set y2_list [] set vx_list [] set vy_list []
        repeat smoothing [set mxlist lput mouse-xcor mxlist set mylist lput mouse-ycor mylist]
        set smoothx mean mxlist set xlist lput smoothx xlist
        set smoothy mean mylist set ylist lput smoothy ylist
        set times lput mytime times

        if mytime > 5 [  ; changed from 6
          ;set  x1_list lput (item (mytime - 5) xlist) x1_list
          set  x1_list lput (item (mytime - 4) xlist) x1_list
          set  x1_list lput (item (mytime - 3) xlist) x1_list
          set  x1_list lput (item (mytime - 2) xlist) x1_list
          set  x1_list lput (item (mytime - 1) xlist) x1_list


          ;set  x2_list lput (item (mytime - 4) xlist) x2_list
          set  x2_list lput (item (mytime - 3) xlist) x2_list
          set  x2_list lput (item (mytime - 2) xlist) x2_list
          set  x2_list lput (item (mytime - 1) xlist) x2_list
          set  x2_list lput (item (mytime - 0) xlist) x2_list

          set smooth_x1 mean x1_list
          set smooth_x2 mean x2_list

          ; delta t is 1 unit so velocity is x2-x1 / 1
          set smooth_vx (smooth_x2 - smooth_x1) / 1






        ]
        ;smooth_x1 mean [

        ;;;item index list

        set-current-plot "graph_1"
        set-current-plot-pen "Pos_X"
        if mytime = 6 [plot-pen-up plotxy mytime smoothx plot-pen-down]
        if mytime > 5 [plotxy mytime smoothx]

       if graph_2? [
        set-current-plot "graph_2"
        set-current-plot-pen "Vel_X"
        ;if mytime = 6 [plot-pen-up plotxy mytime smooth_vx plot-pen-down]
        if mytime = 6 [plot-pen-up plotxy mytime smooth_vx]
        if mytime > 7 [plot-pen-down plotxy mytime smooth_vx ]
        ]
      ]

      ask turtles
        ;[ if distancexy mouse-xcor mouse-ycor > 0
            ;[ facexy mouse-xcor mouse-ycor
      [ if distancexy smoothx smoothy > 0
        [ facexy smoothx smoothy
              fd 0.4  ;; 0.4 gives nice smooth lines
              display ] ]
     set mytime mytime + 1
   ]

  ;;========================
    ;; once the user releases the mouse button, we don't need the
    ;; turtle anymore
    [
     set-current-plot "graph_1"
     set-current-plot-pen "Pos_X"
     plot-pen-up

     set-current-plot "graph_2"
     set-current-plot-pen "Vel_X"
     plot-pen-up


     ;plot-pen-reset

     clear-turtles
     set mytime 0
      set xlist []
      set ylist []
    ]
end
