Deer vs Plants

;; defines the types of turtle agents
breed [invasives invasive] ;; creates the invasive plants
breed [natives native] ;; creates the native plants
breed [deer a-deer] ;; creates the herbivores, deer is both singular and plural so "a-deer" is used for one deer

natives-own [age max-life]
invasives-own [age max-life]
globals [ restricted-zone ]

;******************************* SETTING UP THE MODEL *************************************

to setup ;; what to do when the "Setup" button is pressed
  clear-all ;; clears all patches and turtles
  setup-patches ;; calls "setup-patches" procedure
  setup-deer ;; calls "setup-deer" procedure below
  setup-invasives ;; calls "setup-plants" procedure below
  setup-natives ;; calls the "setup-natives procedure below
  reset-ticks
end

;; sets the patch properties background

to setup-patches
  ask patches
   [
    set pcolor 33 ;; sets the patch color to dark brown
   ]
  set restricted-zone patches with [ pxcor >= -5 and pxcor < 5 and pycor >= -5 and pycor < 5 ]

ask restricted-zone
  [
    ifelse enclosure?
    [ set pcolor black ]
    [ set pcolor 33 ]
]
end

;; procedure to create the native plants and set their characteristics

to setup-natives
  create-natives number-of-natives ;; sets the number of natives according to the slider
  ask natives ;; sets the characteristics of the invasives
   [
    setxy random-xcor random-ycor ;; distributes the natives randomly
    set shape "plant" ;; gives them the plant shape
    set color 65 ;; sets the color to bright green
    set size 1.0 ;; makes them small
    set max-life 1000 ;; give them a maximum lifespan of 1000
    set age random max-life ;; set each turtles age between 0 and one half of max-life
  ]
end

;; procedure to create the invasive plants and set their characteristics

to setup-invasives
  create-invasives number-of-invasives ;; sets the number of invasives according to the slider
    ask invasives ;; sets the characteristics of the invasives
    [
      setxy random-xcor random-ycor ;; distributes the invasives randomly
      set shape "plant" ;; gives them the plant shape
      set color 48 ;; sets the color to pale yellow
      set size 1.0 ;; makes them small
      set max-life 1000 ;; give them a maximum lifespan of 1000
      set age random max-life ;; set each turtles age between 0 and max-life
      while
       [
         member? patch-here restricted-zone
       ]
     [
      setxy random-xcor random-ycor
  ]
   ]
end

;; procedure to create the deer and set their characteristics

to setup-deer
  create-deer number-of-deer ;; sets the number of deer according to the slider
  ask deer ;; gives the deer their characteristics
  [
    set shape "color_deer" ;; makes the turtles deer-shaped
    set color 28 ;; sets the color to a light orangish-brown
    set size 2 ;; makes them large enough to see clearly
    setxy random-xcor random-ycor ;; distributes the deer randomly
    while
    [
      member? patch-here restricted-zone
    ]
    [
      setxy random-xcor random-ycor
  ]
  ]
end
;; end of the setup procedures

;;******************************* RUNNING THE MODEL **********************************
To go

  ask deer
  [
    move-deer ;; calls the "move-deer" procedure
    eat-plants ;; calls the "eat-natives" procedure
  ]

  ask natives
  [
    set age age + 1 ;; native plants grow older by 1
    if age > 1000 ;; 1000 is the maximum lifespan
    [
      die
    ]
  ]

  ask invasives
  [
    set age age + 1 ;; invasive plants grow older by 1
    if age > 1000 ;; 1000 is the maximum lifespan
    [
      die
    ]
  ]
tick
;end

ask restricted-zone
  [
    ifelse enclosure?
    [ set pcolor black ]
    [ set pcolor 33 ]
]

;;********************** PLANT REPRODUCTION ***************************

  let native-repro-prob random-float 1.0 ;; creates a random number between 0 and 1

  ;; controls reproduction of native plants calling on the slider
     if any? natives
    [
     let random-native one-of natives ;; limit number of invasives that can reproduce
     ask random-native
      [
       let empty-patches patches with
      [
       not any? turtles-here ;; checks the landscape for empty patches
      ]
        if any? empty-patches ; an empty patch has no plants or deer
      [
       if native-repro-prob < natives-repro ;; compares natives-repro to the random number
       [
        hatch 1
         [
          move-to one-of empty-patches ;; if there are empty patches the plant reproduces and moves new plant to the empty patch
          set age 1
         ]
       ]
      ]
     ]
    ]

  let invasive-repro-prob random-float 1.0 ;; creates a random number between 0 and 1


  ;; controls plant reproduction calling on the slider, sequence based on ticks
  if any? invasives
   [
     let random-invasive one-of invasives ;; limit number of invasives that can reproduce
     ask random-invasive
     [
      let empty-patches patches with
     [
      not any? turtles-here ; an empty patch has no plants or deer
     ]
        if any? empty-patches
       [
        if invasive-repro-prob < invasives-repro
         [
           hatch 1
         [
            move-to one-of empty-patches
            set age 1
         ]
        ]
       ]
      ]
    ]
end

;; ********************* DEER STUFF ****************************

to move-deer
  let move-prob random-float 1.0
    ask one-of deer
    [
     ifelse move-prob < 0.5 and pcolor != black
    [
     right random 360
     forward 1 ;; move the deer in a random direction 1 unit
    ]
    [
      set heading heading - 180
      forward 2
    ]
  ]
end

to eat-plants
  let eat-prob random-float 1.0

  let native-on-patch natives-here ;; check for native plants on a patch
    if any? native-on-patch ;; conditions the action based on presence of a native plant
      [
        ask one-of native-on-patch
      [
        if eat-prob < deer-preference ;; a deer-preference > 0.5 makes it more likely the deer will eat a native
          [
            die
          ] ;; if there is a native plant on a patch with a deer, then the native plant is consumed by the deer
       ]
      ]

  let invasive-on-patch invasives-here
    if any? invasive-on-patch ;; conditions the action based on the presence of an invasive plant
    [
      ask one-of invasive-on-patch
    [
      if eat-prob > deer-preference ;; a deer-preference of <0.5 makes it more likely the deer will eat an invasive
        [
          die
        ]
    ]
  ]
end
